DSSUR[

DSSUR[
0DJQHWLFIOX[GHQVLW\LQP7
'LVWDQFHLQPP
Figure3-2 Schematic representation of the static magnetic 󹪝eld of a secondary section, depending
on distance
Risk to persons as a result of strong magnetic 󹪝elds
WARNING
Risk of death as a result of permanent magnet 󹪝elds
Even when the motor is switched o󹪜, the permanent magnets can put people with active
medical implants at risk if they are close to the motor.
Examples of active medical implants include: Heart pacemakers, insulin pumps.
• As the a󹪜ected person, maintain a minimum distance of 500 mm from the permanent
magnets (trigger threshold for static magnetic 󹪝elds of 0.5 mT as per directive 2013/35/EU).
With regard to the e󹪜ect of strong magnetic 󹪝elds on people, the DGUV rule 103-013
"Electromagnetic Fields" of the German Social Accident Insurance applies in Germany.
This rule speci󹪝es all the requirements that must be observed in the workplace. In other
countries, the relevant applicable national and local regulations and requirements must be
taken into account.
Description
3.1Technical features and ambient conditions
Naturally-Cooled 1FN3 Linear Motors
30 Operating Instructions, 06/2023, A5E52220465B AB
