Standards and Approvals
A-132
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
A.1 Electromagnetic compatibility
Definition
Electromagnetic compatibility is the ability of an electric device to function satisfac-
torily in its electromagnetic environment without interfering with its environment.
The requirements fulfilled by the C230-2 include those of the EMC Statute of the
Single European Market.
Below you will find information on immunity to noise and data on radio interference
suppression.
Pulse-shaped interference
The following table shows the electromagnetic compatibility of modules with regard
to pulse-shaped interference.
Pulse-shaped interference Tested with Corresponds to
severity
Electrostatic discharge n accordance
with IEC 801-2 (DIN VDE 0843
Part 2)
8 kV
4 kV
3 (air discharge)
2 (contact discharge)
Burst pulses (rapid transient interfer-
ence) in accordance with
IEC 801-4 (DIN VDE 0843 Part 4)
2 kV (supply line)
2 kV (signal line)
3
Surge in accordance with
IEC 801-5 (DIN VDE 0839 Part 10)
Only with protection elements
S Asymmetrical connection 2 kV (supply line)
2 kV (signal line/data line) 3
S Symmetrical connection 1 kV (supply line)
1 kV (signal line/data line)
