Device Data
3-55
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
3.5 Dimension drawing
125
200
130
120
180
C230-2
Fig. 3-10 Dimension drawing of the C230-2
