Siemens SIMOTION C230-2 Equipment Manual

Device Data
3-35
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
3.1.7 Measuring system interface
Connectors to the encoder
A 15-pin Sub-D socket for the connection of incremental or absolute encoders
(SSI) is provided for each axis.
Position of the connectors
Fig. 3-6 shows the mounting position and designation of the connectors on the
module.
1
15
8
9
X3...X6
ENCODER 3, 4
ENCODER 1, 2
X2
X3 X4
X6X5
X1
X9 DP2/MPIX8 DP1
C230-2
SIEMENS
X7
Fig. 3-6 Position of connectors X3 to X6
