Device Data
3-27
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
3.1.4 PROFIBUS DP and drive interface
PROFIBUS DP interface (X8, X9)
The C230-2 provides you with two interfaces for connection to the PROFIBUS DP.
Baud rates up to 12 Mbits/s are possible. Both interfaces can be used for isochro-
nous operation.
The interfaces can be operated in the following combinations as master or slave
(isochronous/not isochronous):
X8 X9 Remark
Actions in the
application
1)
DP slave
isochronous
DP master
isochronous
Application synchronized with
DP master (X9), application
controls synchronization with
DP slave (X8)
DP master/DP slave
synchronization mech-
anisms
DP master
isochronous
DP slave
isochronous
Application synchronized with
DP master (X8), application
controls synchronization with
DP slave (X9)
DP master/DP slave
synchronization mech-
anisms
DP slave
isochronous
DP master not
isochronous
Application running freely or
synchronized to the DP slave
(X8)
(can be monitored by the ap-
plication)
DP slave synchroniza-
tion mechanisms
DP master not
isochronous
DP slave
isochronous
Application running freely or
automatically synchronized to
the DP slave (X9)
(can be monitored by the ap-
plication)
DP slave synchroniza-
tion mechanisms
DP master
isochronous
DP master
isochronous
Application synchronized with
DP master (X8, X9)
None
DP master
isochronous
DP master not
isochronous
Application synchronized with
DP master (X8)
None
DP master
isochronous
DP slave not
isochronous
Application synchronized with
DP master (X8)
None
DP master not
isochronous
DP master
isochronous
Application synchronized with
DP master (X9)
None
DP slave not
isochronous
DP master
isochronous
Application synchronized with
DP master (X9)
None
DP master not
isochronous
DP master not
isochronous
Application asynchronous None
DP slave not
isochronous
DP master not
isochronous
Application asynchronous None
DP master not
isochronous
DP slave not
isochronous
Application asynchronous None
1) Actions in the application see function description SIMOTION Modular Machine Con-
cepts, order no. see List of References
