Device Data
3-28
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
If both interfaces (X8, X9) are to be operated isochronously, then they must both
be configured with the same DP cycle clock.
The X9 can alternatively be used as an MPI interface with a baud rate of up to
12 MBit/s.
Connectable devices
The following devices can be connected to the PROFIBUS DP interfaces:
S PG/PC
S SIMATIC HMI devices
S S7 controllers with PROFIBUS DP interface
S Distributed I/Os (e.g. ET 200M)
The updating of the digital inputs/outputs is carried out in the position control
cycle clock.
S C230-2
S Teleservice adapter
S Drives with digital interface (e.g. SIMODRIVE 611 universal)
Note
A teleservice adapter can only be connected to one of the two interfaces.
All approved modules and devices are listed in the PM 10 catalog and in Subsec-
tion 3.1.5. Refer to the list of references for the order number.
Please note the documentation regarding the individual modules or devices!
