Siemens SIMOTION C230-2 Equipment Manual

Device Data
3-36
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
Connector pin assignment
Designation: X3, X4, X5, X6 ENCODER 1...4
X3 Axis 1
X4 Axis 2
X5 Axis 3
X6 Axis 4
Type: 15-pin Sub-D socket connector
Table 3-7 Assignment of connectors X3 to X6
Encoder Encoder
Pin
Incremental Absolute
Type Pin
Incremental Absolute
Type
1 Unassigned 9 MEXT VO
2 CLS O 10 Z I
3 CLS_N O 11 Z_N I
4 P5EXT VO 12 B_N I
5 P24EXT VO 13 B I
6 P5EXT VO 14 A_N DATA_N I
7 MEXT VO 15 A DATA I
8 Unassigned
Signal names
A, A_N Track A non-inverted and inverted (incremental encoder)
B, B_N Track B non-inverted and inverted (incremental encoder)
Z, Z_N Zero mark non-inverted and inverted (incremental encoder)
CLS, CLS_N SSI cycle clock shift pulse non-inverted and inverted (absolute
encoder)
DATA, DATA_N SSI data non-inverted and inverted (absolute encoder)
P5EXT +5 V supply
P24EXT +24 V supply
MEXT Ground supply
Signal type
VO Voltage output (supply)
O Output (5 V signal)
I Input (5 V signal)
