Siemens SIMOTION C230-2 Equipment Manual

Product Overview
1-15
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
Distributed I/Os
Table 1-2 C230-2 with distributed I/Os
Component
Function
C230-2 ... is the motion control module.
S The C230-2 communicates via two PROFIBUS DP inter-
faces with the:
– Programming device (PG/PC)
– SIMATIC HMI devices
– S7 controllers with PROFIBUS DP interface
– I/O systems ET 200
– Drive units
– Further C230-2s
S The C230-2 communicates via an Ethernet interface with
the programming device (PG/PC).
Note:
All approved devicles are listed in the PM 10 catalog and in
Subsection 3.1.5.
Table 1-3 Further components that can be connected to the C230-2
Component
Function
Programming device
(PG/PC)
... configures, parameterizes, programs and tests SIMOTION
and C230-2.
SIMATIC HMI device ... is used for operating and monitoring functions. It is not abso-
lutely essential for the operation of a C230-2.
Note:
All released modules are listed in the PM 10 catalog.
Drive units ... convert speed setpoints into signals for controlling the motor
and provide the power required to operate the motors.
Note:
All released modules are listed in the PM 10 catalog.
