Device Data
3-21
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
Interfaces
The interfaces and their functions are described in Table 3-1.
Table 3-1 Interfaces
Interfaces
Description
Bus connector A rear-mounted connector for connecting the C230-2 with
other S7-modules over the P-bus
Drive interface 50-pin Sub-D connector X2 for the analog connection of
drives (max. 4 axes)
See Subsection 3.1.6
Measuring system interface 15-pin Sub-D sockets X3 to X6 for connection of encoders
(max. 4)
See Subsection 3.1.7
I/O interface 40-pin front connectors X1 for connecting the fast digital
inputs/outputs including measuring inputs, BEROs, and for
wiring the READY relay
See Subsection 3.1.8
Power supply connection 4-pin screw-type terminal connection X10 for connecting
the 24 V load power supply
See Subsection 6.2.1
Memory module slot 7-pin connector for Micro Memory Card
See Subsection 3.1.2
PROFIBUS DP1 interface 9-pin Sub-D socket X8 for connection to the PROFIBUS
DP. This interface can be used for isochronous operation.
See Subsection 3.1.4
PROFIBUS DP2/MPI
interface
9-pole X9 Sub-D socket for connection to PROFIBUS DP
(default setting) or an MPI bus.
This interface can be used for isochronous operation.
See Subsection 3.1.4
Ethernet interface 8-pin RJ45 socket X7 for connection to a Fast Industrial
Ethernet
