Installation
4-63
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
2-tier layout
Fig. 4-4 shows the 2-tier layout with C230-2.
PS C230-2 IM 365 S
IM 365 R I/O modules
Rack 1
Rack 0
Connection cable
I/O modules
Fig. 4-4 Layout of modules on two racks
