Wiring
6-84
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
Overview of connections – Connecting cable
Incremental encoder 6FX2 001–2...
with RS422 (TTL)
Linear scale with EXE
Absolute encoder 6FX2 001–5...
with SSI
C230-2
X1
Digital inputs/outputs
X2
SIMODRIVE 611 analog/universal
4 setpoints
6FX2 002-3AD01-1VV0
v 35 m Open strand ends
X3 to X6
6FX2 002-2CE02-1VV0
v 35 m
6FX2 002-2CD01-VVV0
v 35 m at 5 VDC
SIMODRIVE 611 universal with
incremental shaft encoder (WSG)
interface
6FX2 002-2CJ10-1VV0
v 50 m
SIMODRIVE 611 analog closed-loop
control module for 1FK6 motors with
resolver
6FX2 002-2CJ00-1VV0
v 50 m
6FX2 002-2CC11-VVV0
v 50 m at 500 kbit/s
v 300 m at 125 kbit/s
6FX2 002-2CD01-1VV0
v 25 m
PROFIBUS bus cable
PROFIBUS DP node
X8
and
X9
1FT5 servo motor with integrated
ROD 320
X7
Ethernet bus cable
Ethernet node
Fig. 6-3 Overview of connections
