Conversion from upgraded projects to symbolic assignment is possible, but this requires post-
editing
of the project, especially for free telegram configurations (e.g. for TM15 DI/DO, TM31).
Note
If the symbolic assignment is activated later, previously existing telegram settings and BICO
interconnections for all SINAMICS telegrams that are set to Standard/Automatic
(Communication -> Telegram configuration) are replaced at the next compilation. This may
change telegrams and BICO interconnections and delete telegram extensions previously set
up manually.
For
this reason, make a backup copy of your project before activating the symbolic assignment.
To retain the settings that have been made, after the selection of "Use symbolic assignment,"
the setting "User-defined" must be selected and the check box cleared for automatic telegram
setting/address adaptation for the respective message before compilation.
For further details, see the
SIMOTION Runtime Basic Functions Function Manual.
Assigning a drive later
You
can create an axis in SIMOTION SCOUT and assign it to a drive later. You can thus load
your user program to the controller and (with the exception of the non-existent drives) test it.
Compared to a procedure with temporarily created "virtual axes", "axes without assigned drive"
have the advantage that the configuration data is completely available and do not require a
"virtual axis -> real axis" reconfiguration.
Simulation of axes
You can also use the axis simulation to test the user program. You can find a script for switching
the axis simulation on and off in SIMOTION Utilities & Applications, which is part of the scope
of delivery of SIMOTION SCOUT.
Further details can be found in the
TO Axis Electrical/Hydraulic, External Encoder Function
Manual.
Adaptation
In addition to the symbolic assignment, the automatic adaptation also facilitates the
configuration of SINAMICS S120 data. When SIMOTION devices ramp up, reference
variables, along with drive and encoder data for SINAMICS S120, are transferred automatically
for the configuration data of the SIMOTION technology objects "Axis" and "External Encoder".
This data no longer has to be entered in SIMOTION.
For additional information, see the following sources:
● SIMOTION Runtime Basic Functions Function Manual
● TO Axis Electrical/Hydraulic, External Encoder Function Manual
Commissioning (software)
7.1 Overview of commissioning
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 141
