PROFIBUS DP
SIMOTION D410-2 can communicate with the following components via the PROFIBUS DP
interface.
Table 2-2
Components on PROFIBUS DP
Component Function
Programming device (PG/PC) … configures, assigns parameters, programs, and tests using the SIMOTION SCOUT En‐
gineering System (ES).
SIMATIC HMI device ... is used for operating and monitoring functions. This is not an essential requirement for
the operation of the SIMOTION D410-2.
Other controllers (e.g. SIMO‐
TION or SIMATIC)
… e.g. higher-level controller (plant controller); modular machine concepts with multiple
controllers, distributed across individual machine modules.
Distributed I/O systems
SIMATIC ET 200MP Modular I/O system for cabinet installation and high channel densities in the SIMAT‐
IC S7‑1500 packaging system. SIMATIC ET 200MP permits the shortest bus cycle times
and fastest response time even with large volumes of data.
SIMATIC ET 200M Modular I/O system for cabinet installation and high channel densities in the SIMAT‐
IC S7‑300 packaging system.
SIMATIC ET 200SP Finely scalable I/O system for cabinet installation; ET 200SP features a single-cable and
multi-cable
connection with push‑in terminals, compact dimensions, high performance, and
low part variety.
SIMATIC ET 200S Finely scalable I/O system for control cabinet installation and particularly time-critical appli‐
cations; including motor starters, safety technology and individual grouping of load groups.
SIMATIC ET 200pro Modular I/O system with IP65/IP67 degree of protection for machine-related applications
with
no control cabinet; with features such as more compact designs, integrated PROFIsafe
safety technology, PROFINET connection, and live module replacement.
SIMATIC ET 200eco I/O system with IP65/IP67 rating for machine-related applications with no control cabinet,
with a flexible and fast connection system in ECOFAST or M12.
Other PROFIBUS I/O
Gateways
● DP/AS-Interface Link 20E and DP/AS-Interface Link Advanced for the PROFIBUS DP
gateway to AS-Interface
●
DP/DP coupler for connecting two PROFIBUS DP networks
Drive interfaces
● ADI4
(Analog Drive Interface for 4 axes) for the connection of drives with analog ±10 V
setpoint interface or for external encoders
● IM 174 (Interface Module for 4 axes) for the connection of drives with analog ±10 V
setpoint interface, external encoders or the connection of stepper drives with pulse/
direction interface
Drive units with PROFI‐
BUS DP interface
(e.g. CU310-2 DP)
... convert speed setpoints into signals for controlling the motor and supply the power re‐
quired to operate the motors.
Can also be operated as an isochronous slave on the PROFIBUS DP.
Teleservice adapter Remote diagnostics
Description
2.2 System components
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 29
