PROFINET IO
The SIMOTION D410‑2 DP/PN can communicate with the following components via the
onboard PROFINET IO interface.
Table 2-3
Components on the PROFINET IO
Component Function
Programming device (PG/PC) … configures, assigns parameters, programs, and tests using the SIMO‐
TION SCOUT Engineering System (ES).
SIMATIC HMI device ... is used for operating and monitoring functions. This is not an essential require‐
ment for the operation of a control unit.
Other controllers (e.g. SIMOTION or SI‐
MATIC)
… e.g. higher-level controller (plant controller); modular machine concepts with
multiple controllers, distributed across individual machine modules.
Master computer … communicates with other devices via UDP, TCP/IP.
Distributed I/O systems
SIMATIC ET 200MP Modular I/O system for cabinet installation and high channel densities in the SI‐
MATIC
S7‑1500 packaging system. SIMATIC ET 200MP permits the shortest bus
cycle times and fastest response time even with large volumes of data.
SIMATIC ET 200M Modular I/O system for cabinet installation and high channel densities in the SI‐
MATIC S7-300 packaging system.
SIMATIC ET 200SP Finely scalable I/O system for cabinet installation; ET 200SP features a single-
cable
and multi-cable connection with push‑in terminals, compact dimensions, high
performance, and low part variety.
SIMATIC ET 200S Finely scalable I/O system for control cabinet configuration and particularly time-
critical applications; including motor starters, safety technology and individual
grouping of load groups.
SIMATIC ET 200pro Modular I/O system with IP65/67 degree of protection for machine-related appli‐
cations
with no control cabinet; with features such as compact designs, integrated
PROFIsafe safety technology, PROFINET IO connection and live module replace‐
ment.
SIMATIC ET 200eco PN Compact block I/O with IP65/66/67 degree of protection for cabinet-free usage in
machines with M12 connection method. Very rugged and resistant encapsulated
metal enclosure.
Other PROFINET IO I/O devices
Drive units with PROFINET IO interface ... convert speed setpoints into signals for controlling the motor and supply the
power required to operate the motors.
Gateways
● IE/AS-Interface link PN IO for the PROFINET IO gateway to AS-Interface
●
PN/PN coupler for connecting two PROFINET IO networks
Description
2.2 System components
SIMOTION D410-2
30 Commissioning and Hardware Installation Manual, 01/2015
