Figure 5-6 Mounting the standard mounting rail clip
Standard rail mounting
Steps for mounting on standard rail
Proceed as follows:
1. First place the SIMOTION P320-4, which is equipped with rail clips, at an angle on the
upper rail guide.
2. Press the SIMOTION P320-4 slightly downward.
3. Swivel the SIMOTION P320-4 completely onto the rail until both clamps lock completely
into place.
Ensure that the locking into place of the SIMOTION P320-4 is audible.
Mounting
5.6 Installing the SIMOTION P320-4 in the control cabinet
SIMOTION P320-4 E / P320-4 S
Commissioning and Hardware Installation Manual, 11/2016 89

Siemens SIMOTION Series Specifications

General

Interfaces	PROFIBUS, PROFINET, Ethernet, USB
Programming Languages	LAD, FBD
Safety	Integrated safety functions
Typical Applications	Machine automation, robotics, packaging, printing
Relative Humidity	5% to 95% (non-condensing)
Protection Class	IP20
Certifications	CE, UL, cUL
