9.5.3 Default IP addresses for Windows and SIMOTION P Runtime
Default Ethernet addresses for use from Windows and SIMOTION P are preset.
Table 9-2 Default Ethernet address for Windows and SIMOTION P Runtime
Ethernet interface Windows SIMOTION P Runtime
Onboard Ethernet 1 169.254.11.21 169.254.11.22
The default IP address for Windows can result in IP addresses being assigned twice, e.g.
during series commissioning (see Troubleshooting/FAQs (Page 201)).
If DHCP is set under Windows, the IP addresses for Windows are determined automatically.
9.5.4 Communication via an Ethernet interface
If both Windows and SIMOTION use the onboard Ethernet interface X1, the following
configuration is present:
6XEQHWV
URXWHUSRVVLEOH
6,027,21b3
2QERDUG(WKHUQHW;
6,027,2135XQWLPH
,3DGGUHVV
,3DGGUHVV
:LQGRZV
'HIDXOW
*DWHZD\
6,027,21
3
Figure 9-13 Distribution of the IP addresses for Windows and SIMOTION P Runtime
Note
If no change of the default IP addresses is desired, all conditions with the default IP addresses
are fulfilled and no change is required.
Parameter assignment/addressing
9.5 Ethernet communication
SIMOTION P320-4 E / P320-4 S
Commissioning and Hardware Installation Manual, 11/2016 143
