6.5.4 Control and status word 3
Control word 3 (STW3)
Bit Significance Explanation Signal interconnection
in the inverter
1)
Telegram 350
0 1 = fixed setpoint bit 0 Selects up to 16 different fixed
setpoints.
p1020[0] = r2093.0
1 1 = fixed setpoint bit 1 p1021[0] = r2093.1
2 1 = fixed setpoint bit 2 p1022[0] = r2093.2
3 1 = fixed setpoint bit 3 p1023[0] = r2093.3
4 1 = DDS selection bit 0 Changes over between settings
for different motors (drive data
sets).
p0820 = r2093.4
5 1 = DDS selection bit 1 p0821 = r2093.5
6 Not used
7 Not used
8 1 = enable technology controller -- p2200[0] = r2093.8
9 1 = enable DC braking -- p1230[0] = r2093.9
10 Not used
11 1 = enable droop Enable or inhibit speed control‐
ler droop.
p1492[0] = r2093.11
12 Not used
13 1 = no external fault
0 = external fault is active (F07860)
-- p2106[0] = r2093.13
14 Not used
15 1 = CDS bit 1 Changes over between settings
for different operation interfaces
(command data sets).
p0811[0] = r2093.15
1)
If you switch from telegram 350 to a different one, then the inverter sets all interconnections p1020,
… to "0". Exception: p2106 = 1.
Advanced commissioning
6.5 Drive control via PROFIBUS or PROFINET
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 223
