3.4.2 Power module for the SINAMICS G120
PM240-2 for standard applications
The PM240-2 Power Module is available without a filter or with an integrated class A line filter.
The PM240-2 permits dynamic braking via an external braking resistor.
Table 3-9 1-phase/3-phase 200 VAC … 240 VAC, article number 6SL3210-1PB… and 6SL3210-1PC…
Frame size FSA FSB FSC FSD FSE FSF
Power (kW) 0.55 … 0.75 1.1 … 2.2 3.0 … 4.0 11 … 18.5 22 … 30 37 … 55
Table 3-10 3-phase 380 VAC … 480 VAC, article number 6SL3210-1PE…
Frame size FSA FSB FSC FSD FSE FSF
Power (kW) 0.55 … 3.0 4.0 … 7.5 11 … 15 18.5 … 37 45 … 55 75 … 132
Table 3-11 3-phase 500 VAC … 690 VAC, article number 6SL3210-1PH…
Frame size FSD FSE FSE
Power (kW) 11 … 37 45 … 55 75 … 132
PM240-2 with Push-Through technology for standard applications
The PM240-2 Power Module is available with Push-Through technology without a filter or with
an integrated class A line filter. The PM240-2 allows dynamic braking using an external braking
resistor.
Table 3-12 1-phase/3-phase 200 VAC … 240 VAC, article number 6SL3211-1PB…
Frame size FSA FSB FSC FSD FSE FSF
Power (kW) 0.75 2.2 4.0 18.5 30 55
Table 3-13 3-phase 380 VAC … 480 VAC, article number 6SL3211-1PE…
Frame size FSA FSB FSC FSD FSE FSF
Power (kW) 3.0 7.5 15 37 55 132
Table 3-14 3 AC 500 V … 690 V, Article No. 6SL3211-1PH…
Frame size FSD FSE FSE
Power (kW) 37 55 132
Description
3.4 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 39
