10.6.10 Current derating depending on the pulse frequency, 690 V inverters
Article number LO power [kW] LO base load output current [A]
Pulse frequency [kHz] 2 *) 4
6SL3210-1PH21-4 . L0 11 14 8.4
6SL3210-1PH22-0 . L0 15 19 11.4
6SL3210-1PH22-3 . L0 18.5 23 13.8
6SL3210-1PH22-7 . L0 22 27 16.2
6SL3210-1PH23-5 . L0 30 35 21
6SL321 . -1PH24-2 . L0 37 42 25.2
6SL3210-1PH25-2 . L0 45 52 31.2
6SL321 . -1PH26-2 . L0 55 62 37.2
6SL3210-1PH28-0 . L0 75 80 48
6SL3210-1PH31-0 . L0 90 100 60
6SL3210-1PH31-2 . L0 110 115 69
6SL321 . -1PH31-4 . L0 132 142 85.2
*) Factory setting
The permissible motor cable length depends on the particular cable type and the pulse frequency that
has been selected
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
502 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
