Line reactors for PM240-2, 380 V … 480 V
Power Module Power Line reactor
FSA 6SL3210-1PE11-8 . L1,
6SL3210-1PE12-3 . L1,
6SL3210-1PE13-2 . L1
0.55 kW … 1.1 kW 6SL3203-0CE13-2AA0
FSB 6SL3210-1PE14-3 . L1,
6SL321 . -1PE16-1 . L1,
6SL321 . -1PE18-0 . L1
1.5 kW … 3 kW 6SL3203-0CE21-0AA0
FSC 6SL3210-1PE21-1 . L0,
6SL3210-1PE21-4 . L0,
6SL321 . -1PE21-8 . L0
4 kW … 7.5 kW 6SL3203-0CE21-8AA0
6SL3210-1PE22-7 . L0,
6SL321 . -1PE23-3 . L0
11 kW … 15 kW 6SL3203-0CE23-8AA0
FSD … FSF: A line reactor is not required.
Line reactors for PM240-2 Power Module, 500 V … 690 V
A line reactor is not required.
Line reactors for PM240-2, 200 V … 240 V
Power Module Power Line reactor
FSA 6SL3210-1PB13-0 . L0,
6SL3210-1PB13-8 . L0
0.55 kW … 0.75 kW 6SL3203-0CE13-2AA0
FSB 6SL3210-1PB15-5 . L0,
6SL3210-1PB17-4 . L0,
6SL321 . -1PB21-0 . L0
1.1 kW … 2.2 kW 6SL3203-0CE21-0AA0
FSC 6SL3210-1PB21-4 . L0,
6SL321 . -1PB21-8 . L0
3 kW … 4 kW 6SL3203-0CE21-8AA0
6SL321 . -1PC22-2 . L0,
6SL3210-1PC22-8 . L0
5.5 kW … 7.5 kW 6SL3203-0CE23-8AA0
FSD … FSF: A line reactor is not required.
Description
3.5 Components for the Power Modules
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 45
