Article number without filter
Article number with filter
6SL3210-1NE27-5UL0
6SL3210-1NE27-5AL0
6SL3210-1NE28-8UL0
6SL3210-1NE28-8AL0
Power loss 0.99 kW 1.2 kW
Required cooling air flow 80 l/s 80 l/s
Weight without filter 15 kg 15 kg
Weight with filter 22 kg 22 kg
Table 10-19 PM230, IP20, frame size F, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1NE31-1UL0
6SL3210-1NE31-1AL0
6SL3210-1NE31-5UL0
6SL3210-1NE31-5AL0
LO base load power 55 kW 75 kW
LO base load input current 102 A 135 A
LO base load output current 110 A 145 A
HO base load power 45 kW 55 kW
HO base load input current 84 A 102 A
HO base load output current 90 A 110 A
Fuse according to IEC / UL 3NE1224-0 3NE1225-0
Power loss 1.4 kW 1.9 kW
Required cooling air flow 150 l/s 150 l/s
Weight without filter 33 kg 33 kg
Weight with filter 48 kg 48 kg
Technical data
10.3 Technical data, PM230 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 451
