Article no. 6SL3225-0BE33-0AA0 6SL3225-0BE33-7AA0
HO base load output 30 kW 37 kW
HO base load input current 56 A 70 A
HO base load output current 60 A 75 A
Fuse according to IEC
Fuse according to UL
3NA3830
100 A, Class J
3NE1821-0
3NA3832
125 A, Class J
3NE1822-0
Power loss 1.04 kW 1.2 kW
Required cooling air flow 22 l/s 39 l/s
Weight 21 kg 21 kg
Table 10-76 PM250, IP20, Frame size F, 3-ph. AC 380 V … 480 V
Article no. 6SL3225-0BE34-5AA0 6SL3225-0BE35-5AA0 6SL3225-0BE37-5AA0
LO base load output 55 kW 75 kW 90 kW
LO base load input current 102 A 135 A 166 A
LO base load output current 110 A 145 A 178 A
HO base load output 45 kW 55 kW 75 kW
HO base load input current 84 A 102 A 135 A
HO base load output current 90 A 110 A 145 A
Fuse according to IEC
Fuse according to UL
3NA3836
160 A, Class J
3NE1824-0
3NA3140
200 A, Class J
3NE1825-0
3NA3144
250 A, Class J
3NE1827-0
Power loss 1.5 kW 2.0 kW 2.4 kW
Required cooling air flow 94 l/s 94 l/s 117 l/s
Weight 51 kg 51 kg 51 kg
Technical data
10.7 Technical data, PM250 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 507
