Performing basic parameterization
6.1 Control Unit
122 Getting Started, 12/2018, 6SL3097-5AG30-0BP0
Bidirectional digital inputs/outputs
"Drive control > Parameters > Inputs/outputs > Bidirectional digital inputs/outputs"
The bidirectional inputs/outputs of terminals X122 and X132 on the CU (DO1) can be used
by a drive object as well as by a higher-level controller (resource sharing). The assignment
to a terminal is defined by means of BICO interconnections which are either connected to a
controller via the DO1 telegram p0922 = 39x or to a drive object.
You can change the interconnection of the bidirectional digital inputs/outputs on the
input/output component.
● You can assign bidirectional digital inputs/outputs in the function. This means that you
have the option of parameterizing an input or an output.
● Digital inputs are used for the acquisition of digital signals. For example, drive enable
signals can be controlled externally.
● For every digital input signal there is the corresponding inverted signal which can also be
used for interconnection.
● Digital outputs are used for the feedback of signals such as enables.
Changing the view of the screen form
The view of this screen form can be reduced to the essentials via a checkbox. Changing the
function of one of the bidirectional digital inputs/outputs is not possible in the optimized view.
The view of the screen form can also be switched to a simulation mode. This switchover only
functions in online mode.
1. If you want to optimize the view, activate the "Optimize view" option.
2. If you want to switch to a simulation from the terminal evaluation, select "Simulation" in
the drop-down list of a digital input.
Parameterizing digital inputs 8 to 15 or digital outputs 8 to 15
Each of the bidirectional digital inputs/outputs can be parameterized as an input or output
using the selector.
Digital input
Default setting when calling the screen form the first time.
Digital inputs 8 to 15 can be interconnected with this switch position. Several
interconnections are possible.
The selector can be switched by clicking from digital input to digital output.
Digital output
Digital outputs 8 to 15 can be interconnected with this switch position. Several
interconnections are possible.
The selector can be switched by clicking from digital output to digital input.
