Performing basic parameterization
6.3 Drive axes
148 Getting Started, 12/2018, 6SL3097-5AG30-0BP0
6.3.2
VECTOR drives
6.3.2.1
Basic parameterization of the drive axes
During the basic configuration, not all of the available options are displayed in the drop-down
list "Basic parameterization". The following table lists the available options for the basic
parameterization of a VECTOR drive axis or axes – and the dependency regarding display
and selectability of options during the basic parameterization.
Note
Dynamic display of options
The display of certain options is dynamic, and depends on the settings, which are carried out
within another option other than the required option. In the "Basic parameterization" list, the
"Mechanical system" option is only displayed if beforehand, the "Basic positioner" function
module was acti
vated (see Chapter "Function modules (Page 148)").
Precondition
● The VECTOR drive axis is OFFLINE.
6.3.2.2
Function modules
☐
"Drive axis > Parameters > Basic parameterization > Function modules"
When required, during the basic parameterization you can switch-in various function
modules for the selected drive axis.
Note
You can only activate and deactivate function modules OFFLINE.
Note
The display of the function modules that can be activated is dynamic and depends on the
selected drive axis and the configuration of this drive axis.
