Commissioning
5.4 Creating a project offline in Startdrive
Getting Started, 12/2018, 6SL3097-5AG30-0BP0
71
Inserting the drive unit offline
Precondition
You have created a project (Page 69) or have opened an existing project.
Inserting a drive unit via the project view
Proceed as follows to insert new drive units in the project view:
1. Double-click "Add new device" in the project navigation.
The dialog with the same name opens.
2. Click "Drives" to display the drives available.
3. Select the desired S120 drive unit in the list.
Figure 5-5 Dialog: Adding a new drive unit
