Siemens SINAMICS S120 - Page 72

Commissioning
5.4 Creating a project offline in Startdrive
70 Getting Started, 12/2018, 6SL3097-5AG30-0BP0
Creating a new project
You can create new projects once the Startdrive application has been opened in the TIA
Portal.
1. In the Startdrive Project view, select "Project > New".
The "Create a new project" dialog box opens.
Figure 5-3 Creating a new project
2. Enter the project data here:
Project name
Startdrive automatically counts each new project.
Path The simpler the archive path for the project, the faster the project can be
loaded.
Author
The login code for the person entering the data is preassigned.
Comment
You can save brief project information here.
3. Click on "Create" to save basic project data.
A new project is created in the Project tree and simultaneously opened.
Figure 5-4 Project created (in the Project view)
You an now insert a new drive.
