6.9 Assignment of terminals and connectors
SINAMICS DCM DC Converter
168 Operating Instructions, 12/2018, A5E34763375A
6.9
Assignment of terminals and connectors
NOTICE
Damage or destruction of the device as a result of incorrect connection
Connecting the device incorrectly can lead to damage or destruction.
Power cables and busbars must be mechanically fastened in place outside of the device.
NOTICE
Dimensioning the connection cables
The information regarding the connection capability of the terminals in the tables below is
based on values from the terminal data sheets. The connecting cables must be
dimensioned for the currents that will flow.
Overview
Table 6- 21 Terminals and connectors overview
1U1, 1V1, 1W1, 1C1, 1D1
Armature circuit
3U1, 3W1, 3C, 3D Field circuit
4U1, 4V1, 4W1, 4N1
Fan
5U1, 5W1, 5N1
Devices with "Power interface with AC electronic power supply"
XP24V
Devices with "Power interface with DC electronic power supply"
X100, X101
DRIVE-CLiQ
X126
PROFIBUS
X165, X166
Parallel interface
X177
for option G63:
X177_1, X177_2, X177_5
Analog inputs, digital inputs, digital outputs, setpoints, reference voltage (P10/N10), serial
interface (peer-to-peer), incremental encoder, analog outputs, temperature sensor
X178, X179
Interface to AOP30, USS interface
XR1
Relay output for line contactor (up to 240 V)
XS1
Safety shutdown E-STOP
XT1
Analog tachometer
X200, X201
Functional safety
