Siemens SINAMICS Series User Manual

Commissioning
8.1 Commissioning checklist
SINAMICS DCM DC Converter
270 Operating Instructions, 12/2018, A5E34763375A
8.1
Commissioning checklist
8.1.1
Commissioning checklist
Preparation
● Read the safety instructions in Chapter "Safety instructions (Page 17)".
● Read Chapter "Transportation, unpacking, installation (Page 77)".
● Work through the entire checklist together with another person before starting work on the
device.
● Before commissioning the converter, as a minimum, check the following points:
Mechanical installation
Use the following checklist to guide you through the mechanical installation procedure for the
device.
Note
Checking the checklist
Check the boxes accordingly in the right
-hand column if the activity applies to the cabinet
unit in your scope of supply. In the same way, check the boxes once you have finished
the
installation procedure to confirm that the activities are complete.
Item
Activity
Available
Completed
1
The device is properly mounted on a vertical wall made of non-flammable material.
2
All shield connections are tight (see Chapter "Connecting (Page 91)").
3
All cable connections are tight (see Chapter "Connecting (Page 91)").
4 The ambient conditions are complied with (see Chapter "Environmental
requirements (Page 44)").
5 The cooling air can flow unobstructed (see fan, airflow rate in Chapter "Unit data
(Page 45)").
6
The motor and driven machine are ready to start.
