Operation
9.2 Parameterizing using the BOP20 (Basic Operator Panel 20)
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
379
9.2.4
Controlling the drive using the BOP20
When commissioning the drive, it can be controlled via the BOP20. A control word is
available on the Control Unit drive object (r0019) for this purpose, which can be
interconnected with the appropriate binector inputs of e.g. the drive.
The interconnections do not function if a standard PROFIdrive telegram was selected as its
interconnection cannot be disconnected.
Table 9- 8 BOP20 control word
Bit (r0019)
Name
Example, interconnection parameters
0
ON / OFF (OFF1)
p0840
1 No coast down/coast down (OFF2) p0844
2
No fast stop/fast stop (OFF3)
p0848
7
Acknowledge fault (0 → 1)
p2102
13
Motorized potentiometer, raise
p1035
14
Motorized potentiometer, lower
p1036
Note
For simple commissioning, only bit 0 should be interconnected. When interconnecting bits
0
... 2, then the system is powered-down according to the following priority: OFF2, OFF3,
OFF1.
