6.10 Installation notes for installation according to UL 508C
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
189
6.10
Installation notes for installation according to UL 508C
Note
The following text has been taken from excerpts from the UL file E203250 and is therefore
provided in English.
● "Solid state motor overload protection at 110% of full-load current is provided in each
model", or equivalent.
● "Integral solid state short circuit protection does not provide branch circuit protection.
Branch circuit protection must be provided in accordance with the National Electrical
Code and any additional local codes", or the equivalent.
● Blower motor protection type 3RV1011-0EA1 trimmed to 0.33 A manufactured by
Siemens is to be provided for blower motor type R2D225-RA26-11 in drive model
sizes C and D.
● Blower motor protection type 3RV1011-0GA1 trimmed to 0.50 A manufactured by
Siemens is to be provided for blower motor Type R2D250-RA28-17 in drive model size E.
● Blower motor protection type 3FV1011-0KA1 trimmed to 1.25 A manufactured by
Siemens is to be provided for blower motor Type RH28M-2DK.3F.1R in Drive model
size F.
Table 6- 46 Overview of Frame Sizes (in mm)
Size
Width
Height
Depth
Line voltage (V)
Output current (A)
A
385
268
210
400, 480
15 - 30
B
385
268
250
400, 480, 575
60 - 280
C
625
268
275
400, 480, 575
400 - 600
D
700
268
310
400, 480, 575
760 - 850
E
780
268
435
400, 480, 575
1000 - 1200
F
880
448
505
400, 480, 575
1600 - 3000
