Type spectrum, ordering information
2.5 Accessories
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
33
Table 2- 6 Article numbers for the Advanced Operator Panel AOP30
Advanced Operator Panel AOP30
RS485 connecting cable for connecting the AOP30 to one CUD; 3 m 6RY1807-0AP00
RS485 connecting cable for connecting the AOP30 to two CUDs; 3 m
Additional cable lengths can be ordered as option.
When ordering the RS485 cable with option, the suffix "-Z" must be attached to the article number followed by the order
code for the required option.
Ordering example for a 35 m long cable:
Article number: 6RY1807-0AP00-Z, order code: K35
Mounting kit to increase the degree of protection to IP20
IP20 according to EN 60529
The degree of protection indicates protection against touching and penetration of solid
objects and/or water.
Units in the SINAMICS DCM range are delivered with degree of protection IP00 and
therefore offer no protection against touching or penetration. The mounting kit for units with a
rated DC current up to 850 A increases the degree of protection to IP20.
Degree of protection IP20 offer protection against touching with the finger and penetration of
solid objects greater than 12.5 mm dia, but no protection against water.
See Chapter "Ordering information for options and accessories (Page 30)" for ordering data.
