Descriptions of functions
10.4 Communication via PROFIBUS DP
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
465
Table 10- 34 Additional parameters
Network parameter profile
Network parameter baud rate Any
Communication partner address
PROFIBUS address of the drive unit
Communication partner slot/rack Don't care, 0
Table 10- 35 Variables: "General" tab
Controller Any
Type Depending on the addressed parameter value,
e.g.:
INT: for integer 16
DINT: for integer 32
WORD: for unsigned 16
DB
Parameter number
DBB, DBW, DBD
(data block offset)
Drive object No. and sub-index
Bit 15 ... 10: Drive object No. 0 ... 63
Bit 9 ... 0: Sub-index 0 ... 1023
Or expressed differently
DBW = 1024 * drive object No. + sub-index
Number of elements 1
You can operate a SIMATIC HMI together with a drive unit independently of an existing
controller.
A basic "point-to-point" connection can only be established between two nodes (devices).
The "variable" HMI functions can be used for drive units. Other functions cannot be used
(e.g. "messages" or "recipes").
Individual parameter values can be accessed. Entire arrays, descriptions, or texts cannot
be accessed.
