Descriptions of functions
10.5 Communication via PROFINET IO
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
511
I&M parameter
designation
Format
Size/
octets
Initialization
SINAMICS
parameters
Meaning
I&M 3:
DESCRIPTOR
Visible
string
54 Space
0x20…0x20
p8808[0...53] Text with any comments or notes.
I&M 4:
SIGNATURE
Octet
string
54 Space
0x00…0x00
r8809[0...53] The parameter is automatically populated by
the system, in which case it contains a
functional check signature for the change
tracking with Safety Integrated. The check
signature has the following format:
• The first four octets (0...3) contain the
content of parameter r9781 index 0:
"SI change monitoring checksum
(Control Unit)".
• The second four octets (4...7) contain the
content of parameter r9782 index 0:
"SI change monitoring time stamp
(Control Unit)".
• The remainder (octets 8...53) contains
zeroes.
The I&M data sets 1...3 are stored permanently in the parameters p8806...p8808. Essential
properties of these 3 parameters:
● They can be displayed in the STARTER expert list.
● The SINAMICS "Reset parameter" (p0976 = 1, p0970 = 1) function does not have any
effect on the content of parameters.
● I&M data sets are not changed when the alternative parameter sets are stored or loaded.
The transfer of parameter sets between a memory card and non-volatile device memory
does not have any effect on the I&M data sets.
Overview of important parameters (see SINAMICS DCM List Manual)
•
p8806[0...53]
Identification and Maintenance
1
•
p8807[0...15]
Identification and Maintenance
2
•
p8808[0...53]
Identification and Maintenance
3
•
r8809[0...53]
Identification and Maintenance
4
