B.2 BOP20 status display during power-up
SINAMICS DCM DC Converter
748 Operating Instructions, 12/2018, A5E34763375A
B.2
BOP20 status display during power-up
During power-up, the status of the power-up is briefly displayed on the BOP20.
Table B- 2 Display of the power-up on the BOP20
Displayed value
Meaning
0
Operation
10 Ready
20
Wait for power-up
25 Wait for automatic firmware update of DRIVE-CLiQ components
31
Commissioning software download active
33
Remove/acknowledge topology error
34
End commissioning mode
35
Perform the first commissioning
70
Initialization
80
Reset active
99
Internal software error
The states listed are automatically run through during the commissioning and are normally
not visible.
In the following exceptional cases, power-up is interrupted with display value 33. In this
state, the unit can be parameterized using BOP20, AOP30 and STARTER:
● Differences have been identified between the reference and actual topology.
– Correct the topology (e.g. re-insert the TM component)
– Accept the actual topology into the reference topology by setting p9905=1 or p9905=2.
Ramp-up is continued.
● A memory card with a parameter data set, which comes from a SINAMICS DCM with a
different article number is inserted in the drive
– Accept the parameter data set by setting p9906 = 3. Ramp-up is continued.
● A memory card with a parameter data set from another CUD type is inserted in the drive
(e.g. a parameter data set from the right-hand CUD was loaded into a left-hand CUD, a
parameter data set of a standard CUD was loaded into an advanced CUD)
– Accept the parameter data set by setting p9906 = 3. Ramp-up is continued.
