System
8.6 SYSTEM - "Start-up files" softkeys
Cylindrical grinding
146 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
The individual data groups in the "802D data" area have the following significance:
Note
The sag compensation is ONLY listed if the associated function was activated.
● Data (in text format)
These data are special initialization data and are transferred in an ASCII file.
– Machine data
– Setting data
– Tool data
– R parameters
– Work offset
– Leadscrew error compensation
– Sag compensation
– Global user data
● Commissioning archive (drive/NC/PLC/HMI)
These data constitute a commissioning file for HMI data and are transferred in the binary
format using the HMI archive format.
– Drive machine data
– NC data
– NC directories
– Display machine data
– Leadscrew error compensation
– Sag compensation
– PLC project
– HMI data and applications
● PLC project (*.PTE)
A direct exchange between the control system and programming tool is possible without
conversion with the support of PLC project handling in the programming tool export
format.
● File for license key
Reading-in and reading-out data on a CompactFlash Card (CF card).
'GDWD
&XVWRPHU
&)FDUG
