Programming
10.1 Fundamental Principles of NC Programming
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
231
Address Meaning Value assignments Information Programming
AC Absolute coordinate - The dimension can be specified
for the end or center point of a
certain axis, irrespective of
G91.
N10 G91 X10 Z=AC(20) ;X -
incremental dimension,
Z - absolute dimension
ACC[
axis
] Percentage
acceleration override
1 ... 200, integer Acceleration override for an
axis or spindle; specified as a
percentage
N10 ACC[X]=80 ;for the X
axis 80%
N20 ACC[S]=50;for the
spindle: 50%
ACP Absolute coordinate;
approach position in
the positive direction
(for rotary axis,
spindle)
- It is also possible to specify the
dimensions for the end point of
a rotary axis with ACP(...)
irrespective of G90/G91; also
applies to spindle positioning
N10 A=ACP(45.3) ;
Approach absolute position
of the A axis in
the positive direction
N20 SPOS=ACP(33.1);
Position spindle
ACN Absolute coordinate;
approach position in
the negative direction
(for rotary axis,
spindle)
- It is also possible to specify the
dimensions for the end point of
a rotary axis with ACN(...)
irrespective of G90/G91; also
applies to spindle positioning
N10 A=ACN(45.3) ;
Approach absolute position
of the A axis in
the negative direction
N20 SPOS=ACN(33.1);
Position spindle
ANG Angle for the
specification of a
straight line for the
contour definition
±0.00001 ...
359.99999
Specified in degrees;
one possibility of specifying a
straight line when using G0 or
G1 if only one end-point
coordinate of the plane is
known
or
if the complete end point is
known with contour ranging
over several blocks
N10 G1 X... Z....
N11 X... ANG=...
or contour over several
blocks:
N10 G1 X... Z...
N11 ANG=...
N12 X... Z... ANG=...
AR Aperture angle for
circular interpolation
0.00001 ...
359.99999
Specified in degrees; one
possibility of defining the circle
when using G2/G3
See G2, G3
CALL Indirect cycle call - Special form of the cycle call;
no parameter transfer; the
name of the cycle is stored in a
variable;
only intended for cycle-internal
use
N10 CALL VARNAME ;
variable name
CHF Chamfer;
general use
0.001 ... 99
999.999
Inserts a chamfer of the
specified chamfer length
between two contour blocks
N10 X... Z.... CHF=...
N11 X... Z...
CHR Chamfer;
in the contour
definition
0.001 ... 99
999.999
Inserts a chamfer of the
specified leg length between
two contour blocks
N10 X... Z.... CHR=...
N11 X... Z...
CR Radius for circular
interpolation
0.010 ... 99
999.999
Negative sign - for
selecting the circle:
greater than
semicircle
One possibility of defining a
circle when using G2/G3
See G2, G3
