Software interface
2.1 Screen layout
Cylindrical grinding
26 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
Table 2- 2 Explanation of the screen controls in the note and softkey area
Screen item Display Significance
①
RECALL symbol
Pressing the <RECALL> key lets you return to the higher menu
level.
② Information line
Displays notes and information for the operator and fault states
HMI status information
ETC is possible (pressing this key displays the horizontal
softkey bar providing further functions.)
ಯ/ಯ
Mixed notation active (uppercase/lowercase letters)
RS232 connection active
Connection to commissioning and diagnostic tools (e.g.
Programming Tool 802) active
③
RCS network connection active
④ Softkey bar vertical and horizontal
Display of the softkeys in the document
To make the softkeys easier to locate, the horizontal and vertical softkeys are displayed in
different basic colors.
Horizontal softkey
Vertical softkey
