Software interface
2.1 Screen layout
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
25
Numbering Display Icon Significance
AUTOMATIC
③ Alarm and message line In addition, the following is displayed:
1. Alarm number with alarm text, or
2. Message text
④ Selected part program (main program)
RESET Program canceled / default state
RUN Program is running
⑤ Program state
STOP Program stopped
⑥ Program control in automatic
mode
Note and softkey area
Figure 2-3 Note and softkey area
