Appendix
A.2 Parameter tables of the tool data
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
383
Tx Dy DP22 REAL Additional compens. in Z, length in Z, basic dimension
Tx Dy DP23 REAL (reserved, length 3)
Tx Dy DP24 REAL Reserved
Tx Dy DP25 REAL Reserved
Tx Dy DPC1 REAL Reserved
Tx Dy DPC2 REAL Reserved
Tx Dy DPC3 REAL Reserved
Tx Dy DPC4 REAL Reserved
Tx Dy DPC5 REAL Reserved
Tx Dy DPC6 REAL Reserved
Tx Dy DPC7 REAL Reserved
Tx Dy DPC8 REAL Reserved
Tx Dy DPC9 REAL Reserved
Tx Dy DPC10 REAL Reserved
Table A- 5 7. to 9th cutting edge for dressers
Tx Dy DP1 INT Tool type=403
Tx Dy DP2 INT Cutting edge position (1...9)
Tx Dy DP3 REAL Position
Tx Dy DP4 REAL Position
Tx Dy DP5 REAL Position
Tx Dy DP6 REAL R - Tool nose radius
Tx Dy DP7 REAL Diameter
Tx Dy DP8 REAL Width
Tx Dy DP9 REAL Maximum peripheral speed
Tx Dy DP10 REAL Maximum speed
Tx Dy DP11 REAL Probing data block
Tx Dy DP12 REAL dD - Change in diameter (dressing amount X)
Tx Dy DP13 REAL dL - Change in distance (dressing amount Z)
Tx Dy DP14 REAL (Length 3)
Tx Dy DP15 REAL dR - Change in tool nose radius (radius wear)
Tx Dy DP16 REAL Roller circumference speed
Tx Dy DP17 REAL Maximum length 1 wear
Tx Dy DP18 REAL Maximum length 2 wear
Tx Dy DP19 REAL Maximum length 3 wear
Tx Dy DP20 REAL Roller direction of rotation optional
Tx Dy DP21 REAL Additional compens. in X, diameter, basic dimension
Tx Dy DP22 REAL Additional compens. in Z, length in Z, basic dimension
Tx Dy DP23 REAL (reserved, length 3)
Tx Dy DP24 REAL Z oscillating path
Tx Dy DP25 REAL Infeed amount per stroke
