Appendix
A.2 Parameter tables of the tool data
Cylindrical grinding
384 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
Tx Dy DPC1 REAL Reciprocation speed
Tx Dy DPC2 REAL Dressing amount
Tx Dy DPC3 REAL Approaching distance
Tx Dy DPC4 REAL X start
Tx Dy DPC5 REAL Z start
Tx Dy DPC6 REAL Dresser type (0 – X/Z, >0 rear, rotating,...)
Tx Dy DPC7 REAL Profile depth
Tx Dy DPC8 REAL Safety speed
Tx Dy DPC9 REAL X oscillating path
Tx Dy DPC10 REAL Reserved
In addition to the default coding of the tool data (tool type, cutting edge position, etc.), the
following coded parameters are used.
Encoding Wheel type $TC_TPC1[T]
0 free contour
1 Standard contour straight without rear definitions
2 Standard contour straight with rear definitions
3 Standard contour inclined left
4 Standard contour inclined right
5 Standard contour straight profile roller with geo axes
Encoding Dressing mode at the diameter $TC_DP19[T,1]
0 neither drawing nor plunging (3rd dresser)
1 drawing (last active dresser)
2 plunging (last active dresser)
11 drawing (1st dresser)
12 plunging (1st dresser)
21 drawing (2nd dresser)
22 plunging (2nd dresser)
Encoding Dresser type $TC_DPC6[T,_GC_DNUM+dresser-1]
0 Dresser geometry axes (diamond) non-rotating
1 Dresser geometry axes (diamond) non-rotating
...
11 Dresser, geometry axes (form roll) rotating
12 Dresser, geometry axes (form roll) rotating
21 Dresser, geometry axes (diamond) rotating
