Define
4.2 Create new tool
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
41
In the next step, the tool data are to be entered.
● Nominal dimensions for monitoring
● Geometry data
● Technological data
● Data for the dressers
Nominal dimensions and monitoring
This function opens in input screen into which grinding wheel nominal dimensions and
monitoring data are entered.
Figure 4-6 Grinding wheel nominal dimensions and monitoring data
7RRO
GDWD
1RPLQDO
GLPHQVLRQ
PRQLWRULQJ
