4.10 SINAMICS S120 Combi
4.10.1 S120 Combi status displays
Status displays
The SINAMICS S120 Combi has two LEDs to display the status of the components. The
software assigns a priority to the status signals from the individual components. The most
important and most informative status is output for the complete S120 Combi.
The status is immediately output if any component develops a fault. The ready to run indication
is only issued if all of the components have signaled that they are ready to run.
The LED statuses for the S120 Combi are described in the following table. The status display
always refers to the entire module.
State Description, cause Remedy
RDY DC LINK
Off Off Electronics power supply is missing or outside permissi‐
ble tolerance range.
Connect/test the electronics pow‐
er supply
Green Off The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
-
Orange The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is present.
-
Red The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is too high.
Check the line supply voltage.
Orange Orange DRIVE-CLiQ communication is being established. -
Red - This component has at least one fault.
Note:
The LED is controlled irrespective of the corresponding
messages being reconfigured.
Remove the fault and acknowl‐
edge
Green/Red
(0.5 Hz)
- Firmware is being downloaded.
Green/Red
(2 Hz)
- Firmware has been downloaded.
Wait for POWER ON.
Carry out a POWER ON
Green/Or‐
ange
or
Red/Orange
- Component recognition using LED is activated (p0124)
Note:
Both options depend on the LED status when module
recognition is activated via p0124 = 1.
-
Service cases - hardware
4.10 SINAMICS S120 Combi
Software and hardware
Service Manual, 08/2018, 6FC5397-5DP40-6BA1 137
