4.18.2 TM54F connections
Connections
3URWHFWLYHFRQGXFWRU
FRQQHFWLRQ0bbb1P
6KLHOGFRQWDFW
5'<
;
;
;
;
;
;
;
;
;
;
;
;
;
X501, X500 DRIVE-CLiQ interfaces
X524 Electronics power supply
RDY LEDs for status display
X521, X531
X522, X532
Fail-safe digital inputs DI and dynamic power supply
Fail-safe digital inputs DI
X523, X525, X533,
X535
Fail-safe digital outputs DO
X520 Sensor power supply
X514 Power supply for digital outputs and sensors
Figure 4-62 TM54F connections
Service cases - hardware
4.18 Terminal Modules
Software and hardware
222 Service Manual, 08/2018, 6FC5397-5DP40-6BA1
