6. Insert the DRIVE-CLiQ cable at X500 – X505.
7. Insert connector X524 for the electronics power supply.
4.19.5 DME20 connections
Connections
The component has degree of protection IP67 and is especially suitable for applications which
require DRIVE-CLiQ nodes to be removed in groups, without interrupting the DRIVE-CLiQ line
and therefore the data exchange.
;
;
;
;
;
;
;
;
X500 ... X505 DRIVE-CLiQ interfaces
X524 Electronics power supply
Figure 4-68 DME20 connections
Service cases - hardware
4.19 Hub Modules
Software and hardware
Service Manual, 08/2018, 6FC5397-5DP40-6BA1 231
