4.16 Sensor Modules Cabinet
4.16.1 SMC10/SMC20 status displays
Status displays
Sensor Modules Cabinet-Mounted SMC10 and SMC20 have the following status displays,
which provide information about the module state:
LED Color State Description, cause Remedy
RDY - OFF Electronics power supply is missing or outside
permissible tolerance range.
–
Green Continuous light The component is ready for operation and cy‐
clic DRIVE-CLiQ communication is taking
place.
–
Orange Continuous light DRIVE-CLiQ communication is being estab‐
lished.
–
Red Continuous light This component has at least one fault. Remove and acknowl‐
edge fault.
Note:
The LED is controlled irrespective of the corre‐
sponding messages being reconfigured.
Green/red Flashes at
0.5 Hz
Firmware is being downloaded. –
Flashes at 2 Hz Firmware download has been completed.
Wait for POWER ON
Carry out a POWER ON.
Green/orange or
red/orange
Flashing Component recognition via LED is activated
(p0144)
–
Note:
Both options depend on the LED status when
module recognition is activated via p0144 = 1.
Service cases - hardware
4.16 Sensor Modules Cabinet
Software and hardware
202 Service Manual, 08/2018, 6FC5397-5DP40-6BA1
