3. Mount the fan module in the specified sequence (step ① to step ④):
Figure 4-38 Step ①
Figure 4-39 Step ②
Figure 4-40 Step ③
Service cases - hardware
4.10 SINAMICS S120 Combi
Software and hardware
160 Service Manual, 08/2018, 6FC5397-5DP40-6BA1
