3. Release the temperature sensor input X200 of the SME125.
4. Release the protective conductor connection of the SME125.
5. Remove the defective SME125 module.
Installing
Procedure:
1. Now install the new SME125 module.
2. Screw on the protective conductor connection.
3. Reconnect the temperature sensor at X200.
4. Reconnect the encoder connecting cable.
5. Connect the DRIVE-CLiQ cable.
Note
Connections/cables
The maximum DRIVE-CLiQ cable length is 100 m.
The maximum encoder cable length is 3 m.
In order to guarantee the degree of protection, all of the plug connectors must be correctly
screwed and snapped into place.
Service cases - hardware
4.17 Sensor Modules External
Software and hardware
Service Manual, 08/2018, 6FC5397-5DP40-6BA1 219

Siemens SINUMERIK 828D Series Specifications

General

Display	10.4" TFT color display
Operating System	Embedded Linux
Power Supply	24V DC
Protection Class	IP65 (front), IP20 (rear)
Control Unit Type	CNC
Interfaces	Ethernet, USB, RS232
Programming	ShopMill, ShopTurn, G-code
