1. Press the <SELECT> key, "Normal startup" is the default setting.
2. To call the "Startup menu", press the following keys in succession:
Menu reset key, HSK2 (horizontal SK2), VSK2 (vertical SK2)
Note
PPU with touch operation
To call the startup menu when powering up, there is an additional shortcut for all PPUs: "8"
→ "2" → "8"
3. The Startup menu is displayed:
4. Using the cursor keys, select the menu item "Install software update/backup".
5. Press the <INPUT> key to confirm your selection.
Service cases - software
3.4 Updating the software
Software and hardware
Service Manual, 08/2018, 6FC5397-5DP40-6BA1 53

Siemens SINUMERIK 828D Series Specifications

General

Display	10.4" TFT color display
Operating System	Embedded Linux
Power Supply	24V DC
Protection Class	IP65 (front), IP20 (rear)
Control Unit Type	CNC
Interfaces	Ethernet, USB, RS232
Programming	ShopMill, ShopTurn, G-code
