Siemens SINUMERIK 828D Service Manual

Service cases - hardware
4.6 Expansion module NX10.3
Hardware and Software
112 Service Manual, 03/2011, 6FC5397-5DP40-0BA0
4.6.3 This is how you remove the NX10.3
Preconditions
The activities that are required when replacing an NX10.3 are subsequently described.
If the NX10.3 has a hardware defect, then it must be replaced by an identical module.
● The module is defective and must be replaced.
● The control cabinet is in a no-voltage condition, all of the connectors and cables are
labeled.
Removing
6SDFHUV
&XWRXWVIRU
ODWHUDOPRXQWLQJ
Figure 4-20 Mounting aids

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
