Service cases - hardware
4.14 Sensor Modules Cabinet
Hardware and Software
Service Manual, 03/2011, 6FC5397-5DP40-0BA0
183
4.14.5 SMC30 status displays
Status displays
The Sensor Module Cabinet-Mounted SMC30 has the following status displays, which
provide information about the module state:
LED Color State Description, cause Remedy
- OFF Electronics power supply is missing or outside
permissible tolerance range.
–
Green Continuous light The component is ready and cyclic
DRIVE-CLiQ communication is taking place.
–
Orange Continuous light DRIVE-CLiQ communication is being
established.
–
This component has at least one fault. Red Continuous light
Note:
The LED is controlled irrespective of the
corresponding messages being reconfigured.
Remove and
acknowledge fault.
Flashes at 0.5 Hz Firmware is being downloaded. – Green/red
Flashes at 2 Hz Firmware download has been completed.
Wait for POWER ON
Carry out a POWER
ON.
Component recognition via LED is activated
(p0144)
RDY
Green/orange
or red/orange
Flashing
Note:
Both options depend on the LED status when
module recognition is activated via p0144 = 1.
–
- OFF Electronics power supply is missing or outside
permissible tolerance range.
Power supply ≤ 5 V
-
Electronics power supply for measuring system
available.
Power supply > 5 V.
-
Notice:
OUT > 5 V
Orange Continuous light
It must be ensured that it is permissible to
operate the connected encoder with a 24 V
power supply. If an encoder that is designed for
a 5 V supply is operated with a 24 V supply, this
can destroy the encoder electronics.
